Sanitary Containers 6m HI-FLEX 3 WC 3 Showers

• DX51 (1.5 mm thickness) metallic zinced structure, cold profiled galvanized metal structure, reactive and painted primer according to the RAL palette;
• Water-repellent 18 mm EGGER FIBRE CEMENT;
• Tarkett 1.5 mm PVC linoleum for heavy traffic;

Breaking strain: 400 kg/m².

• DX51 (1.5 mm thickness) metallic zinced structure, cold profiled galvanized metal structure, reactive and painted primer according to the RAL palette;
• RAL 9002 40 mm polyurethane sandwich board;

Breaking strain: 250 kg/m². Support beams are cold profiled, made of galvanized sheet, 1.5 mm thickness. The superior frame has a section which allows the intake of rainwaters and evacuation through the support beams.

• 3 ceramic WC tanks + flushing tanks + PVC toilet seats;
• 3 showers;
• 1 trough sink with mirror;
• 5 liquid soap dispenser;
• 3 metallic dispensers for toilet paper;
• PVC pipes for 110 mm drainage;
• 20 mm PPR pipes for water supply;
• 1 80L boiler;

Electrical installation

• 1 CEE 220-230 V tripolar socket with IP 65;

• automatic fuses box;
• 2 PT SHUKO double sockets;
• 1 PT SHUKO switch;
• 2 18 W LED lamp.

• type C 1 RAL 9002 40 mm sandwich polyurethane board (guaranteed for 10 years);
• 1 and 2 1000×2050 mm metallic RAL 9002 NINZ UNIVER door;
• 2 500x500 mm WHITE PVC window (profile 6 KMG chambers) which can be opened;
